Commend OD10-TD CM-B | Outdoor Intercom Station with 10-inch Touch Display – Black Edition
The Commend OD10-TD CM-B is a flagship outdoor IP intercom station that combines a massive, high-resolution 10-inch capacitive touch display with a sophisticated black finish. Designed to act as a high-visibility digital concierge, it offers an expansive interface for complex directory navigation, corporate branding, and interactive visitor services. The unit features an integrated 1.2-megapixel wide-angle camera for high-definition visual verification and dual digital MEMS microphones providing Ultra HD Voice with a bandwidth of up to 20 kHz.
Housed in a durable black-coated aluminum bezel with a 3 mm tempered glass front, the OD10-TD CM-B is IP65 and IK08 rated, ensuring elite performance and aesthetic longevity in the most demanding outdoor environments.
Key Technical Specifications
| Feature | Specification |
| Model Number | OD10-TD CM-B |
| Display | 10.1-inch TFT Touch Display (1280 x 800 pixels) |
| Camera | 1/3″ RGB CMOS, 1280 x 960 px, Wide-angle |
| Audio Quality | Up to 20 kHz (Ultra HD Voice), OpenDuplex® |
| Color | Black (B) |
| Protection Rating | IP65 (Weatherproof) / IK08 (Impact resistant) |
| Operating Temp | –25 °C to +55 °C (–13 °F to +131 °F) |
| Microphone | Dual digital MEMS microphones |
| Inputs/Outputs | 3 Inputs / 2 Relay Outputs |
| Power Supply | PoE+ (IEEE 802.3at) |
Project Application
The OD10-TD CM-B is designed for large-scale, modern outdoor interaction:
-
Architectural Landmarks: The sleek black finish complements contemporary glass and steel facades while providing a high-tech entrance management system.
-
University & Healthcare Campuses: The large screen is ideal for displaying interactive wayfinding maps and broadcasting emergency instructions in high-visibility areas.
-
Smart City Information Hubs: Provides a rugged yet intuitive interface for public assistance, city services, and secure communication in urban environments.
